Product Description
AGB Gate Valves are engineered for full-bore, bi-directional isolation in high-pressure oil, gas, and power generation pipelines. The through-conduit slab gate design eliminates internal cavities that trap media, making them ideal for pigging operations and services where product contamination must be avoided.
Metal-to-metal seating ensures reliable shutoff even in high-temperature, erosive, or sour service conditions per NACE MR0175. The rising stem design provides a clear visual indication of valve position, while the bolted bonnet allows for easy in-line maintenance without removing the valve from the pipeline.
Available in slab gate and wedge gate configurations, with options for OS&Y (outside screw and yoke) or non-rising stem. All valves are supplied with a full material traceability package and factory hydrostatic test certificate.
Through-Conduit Design
Eliminates cavities for pigging operations and clean-service pipelines.
Metal-to-Metal Seating
Reliable shutoff in high-temperature and erosive service conditions.
Sour Service Rated
NACE MR0175 / ISO 15156 compliant for H2S environments.
Bolted Bonnet
Easy in-line maintenance and repacking without line removal.
Full Technical Specifications
| Product Number | AGB-GV-002 |
| Series | GV Gate Valve |
| Size Range | 2" 56" (DN50 DN1400) |
| Pressure Class | ASME 150 2500 |
| Temperature Range | -46C to +538C |
| Gate Type | Slab gate (through-conduit) & Wedge gate |
| Stem Type | Rising OS&Y / Non-rising |
| End Connection | Flanged RF/RTJ, Butt Weld |
| Body Materials | WCB, LCB, CF8M, Duplex SS, F51, F53 |
| Seating | Metal-to-metal (Stellite overlay), Soft seat |
| Design Standard | API 600, API 602, BS 1414, ASME B16.34 |
| Face to Face | ASME B16.10 |
| Sour Service | NACE MR0175 / ISO 15156 |
| Factory Test | API 598 hydrostatic shell & seat test |
Lead Time: Standard 610 weeks. Large bore (>24") or special alloys 1218 weeks.
Common Applications
Oil & Gas Pipelines
Mainline isolation and pigging operations in transmission pipelines.
Power Generation
Steam and feedwater isolation in thermal and nuclear power plants.
Petrochemical Plants
Process isolation in refineries and chemical processing facilities.
