Product Description
AGB Triple-Offset Butterfly Valves deliver metal-seated, bi-directional, zero-leakage isolation in a compact, lightweight package. The triple-offset geometry eliminates friction between disc and seat during operation, dramatically extending service life compared to conventional double-offset designs.
Available in wafer, lug, and flanged end configurations, these valves are fire-safe certified to API 607 for use in hydrocarbon services. The eccentric disc geometry ensures the seating surface is only contacted at the final degree of closure, eliminating wear during normal operation.
Suitable for large-bore applications where space and weight are critical constraints. All valves are factory-tested to API 598 and supplied with full material traceability documentation and third-party inspection reports on request.
Triple Offset Geometry
Zero friction between disc and seat during operation only contacts at final closure.
Bi-Directional Sealing
Full metal-to-metal seal in both flow directions for complete isolation.
Fire-Safe Certified
API 607 / API 6FA certified for use in hydrocarbon and flammable fluid services.
Wafer, Lug & Flanged
Three end connection options to suit any pipeline configuration.
Full Technical Specifications
| Product Number | AGB-BFV-004 |
| Series | BFV Butterfly Valve |
| Size Range | 2" 120" (DN50 DN3000) |
| Pressure Class | ASME 150 600 (PN 20 PN 100) |
| Temperature Range | -50C to +450C |
| Offset Type | Triple offset (zero friction seating) |
| End Connection | Wafer, Lug, Flanged RF/RTJ |
| Body Materials | WCB, CF8M, Duplex SS, Titanium |
| Disc Materials | 316SS, Duplex, Inconel, Titanium |
| Seat Materials | Metal-to-metal (Stellite), PTFE, RPTFE |
| Design Standard | API 609, EN 593, ASME B16.34 |
| Fire Safe | API 607 / API 6FA certified |
| Factory Test | API 598 shell & seat test |
Lead Time: 610 weeks standard. Large bore (>48 inch) 1218 weeks.
Common Applications
Oil & Gas Pipelines
Large-bore isolation in transmission and distribution pipelines.
Power Generation
Cooling water, condenser, and auxiliary system isolation.
Water Treatment
Municipal water distribution and desalination plant flow control.
